Device Drivers, Part 9: I/O Control in Linux

Input/Output

This article, which is part of the series on Linux device drivers, talks about the typical ioctl() implementation and usage in Linux.

“Get me a laptop, and tell me about the x86 hardware interfacing experiments in the last Linux device drivers’ lab session, and also about what’s planned for the next session,” cried Shweta, exasperated at being confined to bed due to food poisoning at a friend’s party.

Shweta’s friends summarised the session, and told her that they didn’t know what the upcoming sessions, though related to hardware, would be about. When the doctor requested them to leave, they took the opportunity to plan and talk about the most common hardware-controlling operation, ioctl().

Introducing ioctl()

Input/Output Control (ioctl, in short) is a common operation, or system call, available in most driver categories. It is a one-bill-fits-all kind of system call. If there is no other system call that meets a particular requirement, then ioctl() is the one to use.

Practical examples include volume control for an audio device, display configuration for a video device, reading device registers, and so on — basically, anything to do with device input/output, or device-specific operations, yet versatile enough for any kind of operation (for example, for debugging a driver by querying driver data structures).

The question is: how can all this be achieved by a single function prototype? The trick lies in using its two key parameters: command and argument. The command is a number representing an operation. The argument command is the corresponding parameter for the operation. The ioctl() function implementation does a switch … case over the commmand to implement the corresponding functionality. The following has been its prototype in the Linux kernel for quite some time:

int ioctl(struct inode *i, struct file *f, unsigned int cmd, unsigned long arg);

However, from kernel 2.6.35, it changed to:

long ioctl(struct file *f, unsigned int cmd, unsigned long arg);

If there is a need for more arguments, all of them are put in a structure, and a pointer to the structure becomes the ‘one’ command argument. Whether integer or pointer, the argument is taken as a long integer in kernel-space, and accordingly type-cast and processed.

ioctl() is typically implemented as part of the corresponding driver, and then an appropriate function pointer is initialised with it, exactly as in other system calls like open(), read(), etc. For example, in character drivers, it is the ioctl or unlocked_ioctl (since kernel 2.6.35) function pointer field in the struct file_operations that is to be initialised.

Again, like other system calls, it can be equivalently invoked from user-space using the ioctl() system call, prototyped in <sys/ioctl.h> as:

int ioctl(int fd, int cmd, ...);

Here, cmd is the same as what is implemented in the driver’s ioctl(), and the variable argument construct (...) is a hack to be able to pass any type of argument (though only one) to the driver’s ioctl(). Other parameters will be ignored.

Note that both the command and command argument type definitions need to be shared across the driver (in kernel-space) and the application (in user-space). Thus, these definitions are commonly put into header files for each space.

Querying driver-internal variables

To better understand the boring theory explained above, here’s the code set for the “debugging a driver” example mentioned earlier. This driver has three static global variables: status, dignity, and ego, which need to be queried and possibly operated from an application. The header file query_ioctl.h defines the corresponding commands and command argument type. A listing follows:

#ifndef QUERY_IOCTL_H
#define QUERY_IOCTL_H
#include <linux/ioctl.h>

typedef struct
{
	int status, dignity, ego;
} query_arg_t;

#define QUERY_GET_VARIABLES _IOR('q', 1, query_arg_t *)
#define QUERY_CLR_VARIABLES _IO('q', 2)
#define QUERY_SET_VARIABLES _IOW('q', 3, query_arg_t *)

#endif

Using these, the driver’s ioctl() implementation in query_ioctl.c would be as follows:

#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/version.h>
#include <linux/fs.h>
#include <linux/cdev.h>
#include <linux/device.h>
#include <linux/errno.h>
#include <asm/uaccess.h>

#include "query_ioctl.h"

#define FIRST_MINOR 0
#define MINOR_CNT 1

static dev_t dev;
static struct cdev c_dev;
static struct class *cl;
static int status = 1, dignity = 3, ego = 5;

static int my_open(struct inode *i, struct file *f)
{
	return 0;
}
static int my_close(struct inode *i, struct file *f)
{
	return 0;
}
#if (LINUX_VERSION_CODE < KERNEL_VERSION(2,6,35))
static int my_ioctl(struct inode *i, struct file *f, unsigned int cmd, unsigned long arg)
#else
static long my_ioctl(struct file *f, unsigned int cmd, unsigned long arg)
#endif
{
	query_arg_t q;

	switch (cmd)
	{
		case QUERY_GET_VARIABLES:
			q.status = status;
			q.dignity = dignity;
			q.ego = ego;
			if (copy_to_user((query_arg_t *)arg, &q, sizeof(query_arg_t)))
			{
				return -EACCES;
			}
			break;
		case QUERY_CLR_VARIABLES:
			status = 0;
			dignity = 0;
			ego = 0;
			break;
		case QUERY_SET_VARIABLES:
			if (copy_from_user(&q, (query_arg_t *)arg, sizeof(query_arg_t)))
			{
				return -EACCES;
			}
			status = q.status;
			dignity = q.dignity;
			ego = q.ego;
			break;
		default:
			return -EINVAL;
	}

	return 0;
}

static struct file_operations query_fops =
{
	.owner = THIS_MODULE,
	.open = my_open,
	.release = my_close,
#if (LINUX_VERSION_CODE < KERNEL_VERSION(2,6,35))
	.ioctl = my_ioctl
#else
	.unlocked_ioctl = my_ioctl
#endif
};

static int __init query_ioctl_init(void)
{
	int ret;
	struct device *dev_ret;


	if ((ret = alloc_chrdev_region(&dev, FIRST_MINOR, MINOR_CNT, "query_ioctl")) < 0)
	{
		return ret;
	}

	cdev_init(&c_dev, &query_fops);

	if ((ret = cdev_add(&c_dev, dev, MINOR_CNT)) < 0)
	{
		return ret;
	}

	if (IS_ERR(cl = class_create(THIS_MODULE, "char")))
	{
		cdev_del(&c_dev);
		unregister_chrdev_region(dev, MINOR_CNT);
		return PTR_ERR(cl);
	}
	if (IS_ERR(dev_ret = device_create(cl, NULL, dev, NULL, "query")))
	{
		class_destroy(cl);
		cdev_del(&c_dev);
		unregister_chrdev_region(dev, MINOR_CNT);
		return PTR_ERR(dev_ret);
	}

	return 0;
}

static void __exit query_ioctl_exit(void)
{
	device_destroy(cl, dev);
	class_destroy(cl);
	cdev_del(&c_dev);
	unregister_chrdev_region(dev, MINOR_CNT);
}

module_init(query_ioctl_init);
module_exit(query_ioctl_exit);

MODULE_LICENSE("GPL");
MODULE_AUTHOR("Anil Kumar Pugalia <email_at_sarika-pugs_dot_com>");
MODULE_DESCRIPTION("Query ioctl() Char Driver");

And finally, the corresponding invocation functions from the application query_app.c would be as follows:

#include <stdio.h>
#include <sys/types.h>
#include <fcntl.h>
#include <unistd.h>
#include <string.h>
#include <sys/ioctl.h>

#include "query_ioctl.h"

void get_vars(int fd)
{
	query_arg_t q;

	if (ioctl(fd, QUERY_GET_VARIABLES, &q) == -1)
	{
		perror("query_apps ioctl get");
	}
	else
	{
		printf("Status : %d\n", q.status);
		printf("Dignity: %d\n", q.dignity);
		printf("Ego    : %d\n", q.ego);
	}
}
void clr_vars(int fd)
{
	if (ioctl(fd, QUERY_CLR_VARIABLES) == -1)
	{
		perror("query_apps ioctl clr");
	}
}
void set_vars(int fd)
{
	int v;
	query_arg_t q;

	printf("Enter Status: ");
	scanf("%d", &v);
	getchar();
	q.status = v;
	printf("Enter Dignity: ");
	scanf("%d", &v);
	getchar();
	q.dignity = v;
	printf("Enter Ego: ");
	scanf("%d", &v);
	getchar();
	q.ego = v;

	if (ioctl(fd, QUERY_SET_VARIABLES, &q) == -1)
	{
		perror("query_apps ioctl set");
	}
}

int main(int argc, char *argv[])
{
	char *file_name = "/dev/query";
	int fd;
	enum
	{
		e_get,
		e_clr,
		e_set
	} option;

	if (argc == 1)
	{
		option = e_get;
	}
	else if (argc == 2)
	{
		if (strcmp(argv[1], "-g") == 0)
		{
			option = e_get;
		}
		else if (strcmp(argv[1], "-c") == 0)
		{
			option = e_clr;
		}
		else if (strcmp(argv[1], "-s") == 0)
		{
			option = e_set;
		}
		else
		{
			fprintf(stderr, "Usage: %s [-g | -c | -s]\n", argv[0]);
			return 1;
		}
	}
	else
	{
		fprintf(stderr, "Usage: %s [-g | -c | -s]\n", argv[0]);
		return 1;
	}
	fd = open(file_name, O_RDWR);
	if (fd == -1)
	{
		perror("query_apps open");
		return 2;
	}

	switch (option)
	{
		case e_get:
			get_vars(fd);
			break;
		case e_clr:
			clr_vars(fd);
			break;
		case e_set:
			set_vars(fd);
			break;
		default:
			break;
	}

	close (fd);

	return 0;
}

Now try out query_app.c and query_ioctl.c with the following operations:

  • Build the query_ioctl driver (query_ioctl.ko file) and the application (query_app file) by running make, using the following Makefile:
    # If called directly from the command line, invoke the kernel build system.
    ifeq ($(KERNELRELEASE),)

    	KERNEL_SOURCE := /usr/src/linux
    	PWD := $(shell pwd)
    default: module query_app

    module:
    	$(MAKE) -C $(KERNEL_SOURCE) SUBDIRS=$(PWD) modules

    clean:
    	$(MAKE) -C $(KERNEL_SOURCE) SUBDIRS=$(PWD) clean
    	${RM} query_app

    # Otherwise KERNELRELEASE is defined; we've been invoked from the
    # kernel build system and can use its language.
    else

    	obj-m := query_ioctl.o

    endif
  • Load the driver using insmod query_ioctl.ko.
  • With appropriate privileges and command-line arguments, run the application query_app:
    • ./query_app — to display the driver variables
    • ./query_app -c — to clear the driver variables
    • ./query_app -g — to display the driver variables
    • ./query_app -s — to set the driver variables (not mentioned above)
  • Unload the driver using rmmod query_ioctl.

Defining the ioctl() commands

"Visiting time is over," yelled the security guard. Shweta thanked her friends since she could understand most of the code now, including the need for copy_to_user(), as learnt earlier. But she wondered about _IOR, _IO, etc., which were used in defining commands in query_ioctl.h. These are usual numbers only, as mentioned earlier for an ioctl() command. Just that, now additionally, some useful command related information is also encoded as part of these numbers using various macros, as per the POSIX standard for ioctl. The standard talks about the 32-bit command numbers, formed of four components embedded into the [31:0] bits:

  1. The direction of command operation [bits 31:30] -- read, write, both, or none -- filled by the corresponding macro (_IOR, _IOW, _IOWR, _IO).
  2. The size of the command argument [bits 29:16] -- computed using sizeof() with the command argument's type -- the third argument to these macros.
  3. The 8-bit magic number [bits 15:8] -- to render the commands unique enough -- typically an ASCII character (the first argument to these macros).
  4. The original command number [bits 7:0] -- the actual command number (1, 2, 3, ...), defined as per our requirement -- the second argument to these macros.

Check out the header <asm-generic/ioctl.h> for implementation details.
